Twin Seal Flap Damper
Twin Seal Flap Damper – Series 1911
Dual Blade Zero-Leakage Isolation System for Industrial Duct Applications
The Twin Seal Flap Damper – Series 1911 from SUDE Engineering Private Limited is a high-performance isolation damper engineered to provide exceptional shut-off integrity in demanding industrial gas and air ducting systems. Designed for applications where safety, leakage prevention, and operational reliability are critical, this damper utilizes a dual flap blade configuration combined with a pressurized seal air system to achieve zero or near-zero leakage.
The damper operates through a sequential closing mechanism in which the first blade provides primary isolation, while the second blade creates a secondary sealing barrier. Pressurized sealing air is introduced into the cavity between the two blades, forming a positive pressure zone that prevents process gases from passing through the damper. This advanced sealing principle ensures complete isolation even in systems handling high-temperature, abrasive, particulate-laden, or corrosive gases.
Engineered for harsh industrial environments, the SUDE Series 1911 Twin Seal Flap Damper is widely used in power plants, cement plants, steel and metallurgical industries, chemical and petrochemical facilities, incinerators, and pollution control systems. The robust construction and optimized blade geometry minimize deformation under thermal stress, while the sealing system maintains consistent performance across wide temperature and pressure ranges.
The damper design supports both manual and automated actuation, allowing seamless integration with plant control systems. Its reliable isolation capability enhances plant safety during maintenance, start-up, and shutdown operations, while also protecting downstream equipment from unwanted gas ingress. By delivering superior sealing performance and long-term durability, the Twin Seal Flap Damper – Series 1911 reflects SUDE Engineering Private Limited’s commitment to advanced engineering, safety, and high-quality industrial flow control solutions.
Technical Specifications
Parameter
Shapes Available
Rectangular or circular (custom-fabricated to suit duct layout)
Size Range
300 mm to 4000 mm or larger on request
Flow Media
Flue gas, hot air, process gases, or dust-laden exhaust
Blade Type
Dual flap blades (plate or box type)
Sealing Efficiency
Zero or near-zero leakage (Class VI)
Sealing Type
Pressurized seal air chamber between blades
Temperature Range
Up to 800°C or higher with insulation
Material of Construction
Carbon steel, stainless steel, or special alloys
Pressure Rating
Up to 1 bar (higher available upon request)
Drive Operations
Pneumatic or electric actuator with interlock system
Testing Standards
Leak test as per ISO 5208 / API 598 (Class VI)
Design Standards
Custom-engineered as per SMACNA / ASME ducting norms
Working Principle:
Normal Operation
In open position, both flap blades remain fully retracted for free gas flow. During closing, the first flap closes, followed by seal air injection into the intermediate chamber. The second flap closes afterward, ensuring full isolation.
Seal Air Function
Compressed clean air is introduced between the two flaps at slightly higher pressure than the process stream. This prevents any backflow or leakage of process gas downstream.
Actuation Options:
Pneumatic Cylinder
Operated with solenoid valves and limit switches for precise timing.
Electric Actuator
Interlocked for controlled sequencing of both flaps.
Key Features & Advantages
- Achieves true zero-leakage isolation through seal air pressurization
- Ideal for dusty, corrosive, and high-temperature service
- Dual flap design minimizes wear and enhances safety
- Customizable for rectangular or circular ducts
- Ensures environmental compliance and operator safety
Why Choose Twin Seal Flap Damper – Series 1911?
- Zero Leakage Assurance: Proven dual-flap + seal air configuration for perfect shut-off.
- Proven Reliability: Designed for continuous operation in harsh industrial conditions.
- Custom Engineered: Adaptable for all duct geometries and process requirements.
- Automation Ready: Fully compatible with pneumatic and electric control systems.
- Tested Quality: Each damper undergoes functional, leakage, and performance testing before dispatch.
SUDE Twin Seal Flap Damper Advantage:
SUDE Engineering Pvt Ltd. designs and manufactures Twin Seal Flap Dampers with advanced seal-air isolation technology for superior performance in demanding ducting applications.
With robust fabrication, precision actuation, and fully interlocked operation, SUDE dampers deliver maximum sealing efficiency, enhanced durability, and maintenance-free performance even in high-temperature environments.
Applications
Power plant flue gas and air systems
Cement and steel industry exhaust lines
Incinerators and waste gas isolation
ESPs, bag filters, and scrubber inlet/outlet dampers
Hazardous or toxic gas containment systems
