Electric Operated Sluice / Gate Valve
Electric Operated Sluice / Gate Valve – 9650 Series
Electric Operated Sluice / Gate Valves are designed for reliable isolation and flow control in water, steam, and utility pipelines where full bore flow and minimal pressure loss are essential. Operating on the proven wedge gate principle, these valves provide tight shut-off and smooth operation even in high-pressure and high-temperature services.
The valve is operated by a multi-turn electric actuator that enables remote ON–OFF control and seamless integration with PLC / DCS systems. Electric actuation ensures consistent performance, reduced manual effort, and precise valve positioning, making the valve ideal for automated and unmanned installations.
With a robust body construction, precision-machined wedge and seat rings, and corrosion-resistant epoxy coating, electric operated sluice / gate valves offer long service life and dependable operation in demanding industrial and municipal applications.
Technical Specifications
Parameter
Valve Type
Electric Operated Sluice / Gate Valve
Size Range
DN 50 to DN 1200
Pressure Rating for DN 350 to DN 1200
PN 0.6
Pressure Rating for DN 50 to DN 1200
PN 1.0
Pressure Rating for DN 50 to DN 600
PN 1.6
Pressure Rating for DN 700 to DN 1200
PN 0.4
Operating Temperature
Up to 80°C (standard service), Higher temperature on request
Direction of Closure
Clockwise closing (standard) / Anti-clockwise closing (optional)
Actuator Type
Three-phase multi-turn electric actuator
Coating
Fusion Bonded Epoxy (FBE) – internal & external
Design & Construction:
Robust body construction with precision-machined wedge and seat rings combined with fusion bonded epoxy coating ensures corrosion resistance, smooth operation, and long service life.
Working Principle:
Working Principle
Electrical signal rotates actuator spindle
Spindle lifts or lowers wedge vertically
Spindle lifts or lowers wedge vertically
Open Position
Full-bore unobstructed flow
Closed Position
Wedge seats firmly providing tight shut-off
Linear motion ensures reliable isolation without throttling.
Linear motion ensures reliable isolation without throttling.
Automation & Control Options:
- Control Modes: On/Off, Modulating (4–20 mA / 0–10 V)
- Actuator Options: Single Phase, Three Phase, IP67 / IP68, Flameproof (optional)
- Feedback Systems: Limit Switches, Position Transmitter, Potentiometer
- Communication: PLC / DCS Integration (4–20 mA, 0–10 V signals)
- Control Interface: Local Control Panel (LCP), Remote Operation, Integral Starter
Key Features & Advantages
- Full bore design for zero flow obstruction
- Excellent shut-off performance
- Low operating torque due to precision machining
- Smooth and vibration-free operation
- Fusion bonded epoxy coating for corrosion resistance
- Automation-ready electric actuation
- Suitable for frequent open/close cycles
Optional Accessories:
- Position transmitter
- Potentiometer for feedback
- Integral starter
- Local control panel
- Controller
- Thermostat & space heater
- MODBUS communication (RS-485)
Industries Served
HVAC installations
Water distribution networks
Power plants
Industrial utilities
Typical Applications:
Clear water services, sewage systems, plumbing networks, infrastructure pipelines, and automated utility lines.
