Electric Operated 2-Way Plug Valve
Electric Operated 2-Way Plug Valve - 1450 Series
The 1450 Series Electric Operated Plug Valve is a lubricated taper plug valve engineered for reliable ON-OFF and throttling control in a wide range of industrial applications. Designed with a simple yet robust construction, the valve delivers smooth operation, low operating torque, and tight shut-off, even after long periods of continuous service.
These valves are available in regular and short pattern cast-iron construction with square stems to ensure positive torque transmission. For larger sizes, the valve is assembled with heavy-duty electric actuators, carefully selected based on service conditions and operating torque requirements. The motorised design makes the valve ideal for remote operation, automation, and precise flow control.
Technical Specifications
Parameter
Series
1450 Series
Valve Type
Electric Operated Plug Valve
Sizes
15mm to 600mm
End Connections
Flanged
Construction
Regular Pattern / Short Pattern
Body Material
Cast Iron IS 210 Gr. FG220, Cast Steel, Stainless Steel
Plug Material
CI IS 210 FG220 / Carbon Steel ASTM A216 WCB
Valve Action
Normally Open / Normally Closed
Flow Characteristic
ON-OFF / Linear Control up to 60° opening
Operation
Quarter-Turn
Actuator Supply
Single Phase / Three Phase
Mounting
DIN 3210 compatible
Design & Construction:
Lubricated taper plug construction with square stem ensures smooth torque transmission, reduced friction, consistent sealing, and reliable long-term performance.
Working Principle:
Working Principle
The valve operates by rotating a lubricated, tapered plug inside the valve body
Open Position
Plug port aligns with pipeline allowing full flow
Modulating Position
Partial rotation enables controlled throttling
Closed Position
Plug rotates away from flow path providing tight shut-off
The lubrication system reduces friction between plug and body ensuring smooth movement and consistent sealing.
The lubrication system reduces friction between plug and body ensuring smooth movement and consistent sealing.
Automation & Control Options:
- Single Phase Electric Actuator Three Phase Electric Actuator Stay-put type actuators Manual handwheel for emergency operation
- Control Modes: On/Off, Modulating (4–20 mA / 0–10 V), Inching
- Actuator Options: Single Phase, Three Phase, Flameproof / Explosion-Proof
- Feedback Systems: Limit Switches, Potentiometer, Position Indicator
- Position Control: PID Controller (PT-100 Integration), Signal Stimulator
- Communication: PLC / DCS Integration (4–20 mA, 0–10 V, Pulse Signals)
- Control Interface: Local / Remote Control Panel, Integral Starter
Key Features & Advantages
- Lubricated taper plug design for smooth operation
- Low operating torque and reduced actuator load
- Tight shut-off for leak-free service
- Compact quarter-turn operation
- Square stem for positive actuation
- Suitable for frequent operation
- Designed for long service life
Optional Accessories:
- Travel limit switches
- Auxiliary limit switches
- Torque limit switches
- Local position indicator
- Potentiometer for position feedback
- Auto-calibration panel
- Integral starter
- PID Controller with PT-100 sensor
- Signal stimulator
- Single-phase / three-phase control panels
- PLC / DCS integration
Industries Served
Food & Beverage Plants
Chemical & Petrochemical Plants
Pulp & Paper Industry
Atomic Energy Facilities
Typical Applications:
Air, Water, Oil, Gas & Steam systems requiring reliable isolation and throttling control.
