Electric Actuator with Diaphragm Valve
Electric Actuator with Diaphragm Valve – 9850 Series
The Electric Actuator with Diaphragm Valves (9850 Series) from SUDE Engineering Pvt. Ltd. delivers precise, hygienic, and fully automated flow control for critical process applications.
Designed with a high-purity SS316L diaphragm valve and a robust electric actuator, this solution ensures complete isolation between the actuator and process media. The diaphragm-sealed design eliminates dead zones, prevents contamination, and guarantees reliable performance in CIP/SIP systems, WFI loops, purified water lines, clean steam, and sterile fluid handling.
With options for on/off or modulating control, tri-clamp or spigot ends, and automation accessories, the 9850 Series is ideal for modern, automated process plants.
Technical Specifications
Parameter
Body Material
SS316L (ASTM A351 CF3M)
Diaphragm Options
• EPDM (Standard) • PTFE-Backed EPDM (Chemical / High Temperature) • BN, Silicone (Optional)
Actuator Type
Electric actuator (on/off or modulating)
Internal
Ra ≤ 0.4 μm
External
Ra ≤ 0.8 μm
Electro-Polished
Optional (Pharma & high-purity service) End Connections
Pressure Range
As per model specification
Media Temperature
–10°C to +140°C
Ambient Temperature
–10°C to +50°C
Control Signal
Electric (modulating 4–20 mA optional)
Size Range
DN15 to DN50
Design & Construction:
Designed with a high-purity SS316L diaphragm valve and a robust electric actuator, ensuring complete isolation between actuator and process media. The diaphragm-sealed design eliminates dead zones, prevents contamination, and supports hygienic processing requirements.
Working Principle:
Electric Actuation Control
The electric actuator receives a control signal to precisely open or close the valve, ensuring accurate and automated flow regulation.
Advanced Diaphragm Sealing System
A flexible diaphragm seals tightly against the valve seat, preventing leakage and maintaining consistent performance.
Sterile & Reliable Flow Operation
Complete isolation of the actuator from the process media ensures leak-free, hygienic, and dependable flow control in sensitive applications.
Automation & Control Options:
- Electric On/Off Control
- Electric Modulating Control
- Manual override (optional)
- Feedback via limit switches or position sensors
Key Features & Advantages
- Hygienic diaphragm-sealed design with zero contamination
- SS316L high-purity construction for pharma & food use
- Dead-zone-free flow path for CIP/SIP compatibility
- Accurate electric actuation for on/off or modulating control
- Compact, skid-friendly design for tight installations
- Low maintenance with quick diaphragm replacement
- Automation-ready for PLC, SCADA, and DCS systems
Optional Accessories:
- Electric positioner (4–20 mA)
- Valve travel indicator
- Limit switch box with LED
- Proximity sensors
- Stroke limiter
- High-temperature / chemical-resistant diaphragms
Industries Served
Pharmaceutical Industry
Biotechnology Industry
Food & Beverage Industry
Dairy Industry
Typical Applications:
Electric Actuator with Diaphragm Valves (9850 Series) are ideally suited for high-purity, hygienic, and precision-controlled process systems where contamination-free operation and accurate flow regulation are critical. These valves are widely used in pharmaceutical, biotech, and clean utility environments, ensuring reliable automation and strict compliance with hygienic standards.
